| Key parts | | |
| | Panel | SONY 0.63" |
| | Throw Ratio | 1.48~1.78:1 |
| | Zoom Ratio | 1.2X Zoom |
| | Lens Shift | N/A |
| | Light source | LASER |
| Brightness | | |
| ISO21118 | Brightness --MKT | 5000 |
| Brightness --TYP | 4500 |
| Brightness --MIN | |
| Overall Spec | | |
| Light source Life time | FullNormal/Normal mode | 20000hrs |
| ECO1 mode | 30000hrs |
| ECO2 mode | 30000hrs |
| Projection Lens | F | 1.6~1.76 |
| f | 19.158~23.018mm |
| Zoom/Focus | Manual |
| Throw Ratio | 1.48~1.78:1 |
| Zoom Ratio | 1.2x optics |
| Screen size | 30-300 inch |
| Lens Shift | N/A |
| CR | Dynamic Contrast Ratio
(FOFO) | 5000,000:1 |
Native Contrast Ratio
(FOFO) | 400:1(Min) |
| Noise | Noise(dB) | 37dB(Normal) 30dB(ECO1)
28dB(ECO2) |
| Uniformity | Uniformity(Actual Min)
-ISO21118 | 80% |
| AR | Aspect Ratio | Native:4:3 Compatible: 16:9/16:10 |
| Terminal(I/O port) | | |
| Input | VGA | *1 |
| HDMI | *2 |
| Video | *1 |
Audio in
(mini jack,3.5mm) | *1 |
| Audio in (RCA×2) <Audio L/R> | *1 |
| USB-A | *1 |
| USB-B | *1(Display) |
| RJ45 | *1(Display) |
| YCbCr/Component | N/A |
| S-Video | N/A |
| Output | VGA | *1 |
Audio out
(mini-jack,3.5mm) | *1 |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) |
| | Other Interface | N/A |
| General Spec | | |
| Audio | Speaker | 16W*1 |
| Dust filter | W/Filter |
| Filter Life time | 7000h |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
Power Consumption
(Normal) (Max) | 235 |
Power Consumption
(ECO1) (Max) | 175 |
Power Consumption
(ECO2) (Max) | 160 |
| ECO Standby Mode Power Consumption | <0.5W |
| Temp.&Humidity | Operating Temp. | 0 to 40deg.C |
| Operating Thumidity. | 20-80% |
| Storage Temp. | ‘-10 to 50deg.C |
| Storage Thumidity. | 10-85% |
| High altitude | 0-3000m |
| Other Functions | | |
| Keystone | Keystone Correction
(Lens@center) | V: ±30° H:±30°
4 corner |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish,
Swedish, Dutch ,Portugese, Japanese, Simplified Chinese,
Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish,
Norwegian, Danish, Indonesian, Hungarian, Czech,
Kazak,Vietnamese,Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
LAN Control--
AMX Discovery | Yes |
LAN Control--
PJ Link | Yes |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 24~85Hz |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K
@30Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p,
1080i and 1080p |
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC,Auto
Keystone |
| Blank | Yes |
| Suspend | Yes(5miniutes no singnal as default |
| Picture mode | Dynamic,Standard,Cinema, Colorboard,,Blackboard(Green) |
| Cooling time | 5s |
| Closed caption | Yes |
| Auto Ceiling | Yes |
| D-Zoom | 1~19 |
| Others | 360° projection | Yes |
Wireless display
(Optional function) | SmartPhone: Android:Install APK for Android
iphone: Airplay function
PC : Support WiFi
Display@Windows&MAC system through dongle |
| Dimension&Weight | | |
| | MAX Dimensions
(WxDxH mm) | 390*294*128 |
| | Net. Weight (KG) | 5Kg |
| | Packaging Box Dimensions (WxDxH mm) | 492*443*239 |
| | Gross. Weight (KG) | ~6.5Kg |
| Accessory | | |
| | Manual Languages | Chinese,English |
| | Standard Accessaries | Power cord Remote control&RC Battery |
| Regulation List | | |
| WW | CB | √ |
| US | cTUVus | √ |
| FCC | √ |
| FDA | √ |
| EU | CE-EMC | √ |
| CE-LVD | √ |
| CE-ERP | √ |
| IEC60825-1:2007 | class1 | √ |
| EMC Class | | |
| | EMC Class | Class B@3dBm |
