Brand Name : | YEOAN |
Model Number : | TM-65 |
Payment Terms : | L/C, T/T |
Delivery Time : | 30days |
Hardware advantages:
1. Super performance
This solution uses Rockchip PK3288 Cortex-17 quad-core processor,
equipped with Android71 system, with a main frequency of up to
1.8GHz, and uses Mali-T764 GPU.
Supports 4K and H.265 hard decoding.
2. Android system, rich ecology
This solution uses Rockchip PK3288 Cortex-A17 quad-core processor
equipped with Andrid71 system with a main frequency of up to
1.8GHz, and uses Mali-T764 GPU.
Supports 4K and H.265 hard decoding.
3. High cost performance
Compared with the X86 architecture smart motherboard and OPS, the
dual A architecture motherboard and OPS are more economical and
practical, which can help users better control costs, which is a
favorable factor for price-sensitive
users.
Feature:
Professional display screen
The 100-inch interactive multimedia teaching all-in-one machine
uses a professional industrial LCD display screen, which is
completely different from ordinary LCD displays. It has a long
life, high stability, and focuses on special displays.
High-definition picture quality
Full-screen high-definition display, up to 1080P; it has an
ultra-high contrast ratio of 5000: 1, a resolution of 1920 x 1080,
a brightness of 600CD/m, 16.77 million colors, and a 16:9 cinema
playback widescreen, which ensures the richness of the displayed
colors. Regardless of the light, the picture quality is still
clear.
Teaching software
Provide teaching software; the new "ultra-wide viewing angle
extension technology" (S-PVA&S-IPS) creates a 178-degree
viewing angle for all-round viewing.
Dual system settings
Unique unitization and computer modular design; OPS/pull-out PC
settings make maintenance more convenient.
Rich interfaces
The multimedia teaching all-in-one machine has a variety of
interfaces to meet different signal input requirements, including
composite video, component video, VGA, DVI, HDMI, etc. The multiple
input interfaces allow for maximum compatibility and flexibility
when the product is enabled.
Specifications:
Display parameters | |
Panel size | 65" |
Resolution | 3840*2160(pixels) |
Pixel pitch | 0.37*0.37 mm |
Brightness | 350cd/m² (typ.) |
Contrast | 4000:1 (typ.) |
Color | 1.07 B |
Response time | 6.5 ms (typ.) |
Viewable area (H*V) | 1431*806.1 mm |
Angle (H*V) | 178° / 178° |
Service life | 50,000 hrs (typ.) |
Android function parameters | |
Operating system | Android 12 |
Chip | V100 octa-core Cortex-A55*8 1.5GHz |
Storage | 4G RAM 32G RAM |
Resolution | 3840*2160 |
Network | 100M Ethernet/WiFi-2.4G/5G hotspot |
Video format | MPEG2-4,H.264,H.265,TS,Realmedia,etc. |
Image format | JPG, JPEG, BMP, PNG, etc. |
Wireless projection | Support |
Annotation | Support full channel annotation |
Menu language | Chinese/English/Traditional Chinese, etc. |
External connection port | |
Touch USB-B | *1 (front) |
HDMI input | *1 (front) |
USB3.0 (Public) | *2 (front) |
TYPE-C | *1 (front) |
ERP OUT | *1 |
RS232 serial port | *1 |
COAX | *1 |
AV IN | *1 |
RJ45 | *1 |
usb | *2 |
WIFI 2.4G/5G antenna | *4 |
80 PIN INTEL standard port | *1 |
Touch parameters | |
Touch type | Infrared sensor |
Number of touch points | 20 points |
Power supply | |
Speaker power | 15W*2 |
Standby power | ≤0.5W |
Power supply of the whole machine | AC190V-264V,50-60 Hz |
Power of the whole machine (excluding OPS) | ≤200W |
Working environment | |
Working temperature | 0℃~40℃ |
Working humidity | 20%~85% (no condensation) |
Storage temperature | -10℃~60℃ |
Storage humidity | 10%~60% (no condensation) |
Material | |
Shell material | Aluminum frame + tempered glass + metal cover |
Shell color | Black + black |
Size | |
None machine size (W*H*D) | 1488.4*892*91.6 mm |
Packaging outer size (W*H*D) | 1620*1030*200 mm |
VESA hole | 400*400mm, 4*M8 screw |
Weight | |
Net weight | 30 Kg |
Gross weight | 36KG Kg |
Accessories | |
Remote control | *1 |
Power cord | *1 |
Warranty card | *1 |
Certificate of conformity | *1 |
Touch pen | *1 |
Wall mount | *1 |
OPS computer (optional) | CPU: I3/I5/I7 (optional) Memory: 4G/8G/16G (optional) Hard disk: 128G/256G/512G (optional) |
![]() |
